Description

Standard Features

Frame: Heavy duty aluminum frame

Paint: Multiple color options available

Motor: 1/4HP, 1/2HP & 1HP, 115vac, 60Hz or Pneumatic

Filter Heads: Aluminum heads

Pump: Heavy duty gear pump. Available in 1, 2, 5 and 10 GPM

Connections: Various quick connect options available

Hoses: 7ft. Clear PVC, steel reinforced hose or hydraulic hose

Power Switch: Sealed on/off toggle switch

Filter Indicators: Pop up indicator triggers at 50 psid when elements need to be changed.

Pump Relief: Opens at 150psi

Weight: Approx. 45 lbs (will vary depending on options)

Replacement Elements

Part Number	BETA Rating	Desired Cleanliness Level (ISO Code)
P1068	ß3(c)=1000	14/12/9 – 13/11/8
P1069	ß10(c)=1000	18/16/13 – 17/15/12
P1071	ß25(c)=1000	21/19/16 – 20/18/15
P1072WR	Water Removal

All M Series elements measure 5” x 10”.
