SERIES 800 Spring Rewind Reels

Price: $1,169.23$1,800.00 USD

To handle 3/4″ or 1″ I.D. hose Fuel Dispensing (consult factory) / Waste Oil Evacuation / Air / Water
  • Roll-formed channel frame for heavy-duty applications.
  • Non-sparking ratchet assembly.
  • Declutching arbor to prevent damage from reverse winding.
  • Standard inlet: 90° balanced pressure swivel joint, 1″ female NPT threads.
  • Standard outlet: 1″ female NPT threads.
  • Standard pressures to 2,000 psi (138 bar), available up to 6,000 psi (414 bar) – must specify.
  • Standard fluid temperatures from -40° F to +250 °F (-40° C to +121° C). Optional temperature ratings available – consult factory.
  • 4-way roller assembly.
  • SR and VR roller positions: swivel joint is standard on the right, TR roller positions: swivel joint is standard on the left. Optional configurations are available, must specify, click for more information.
  • Constant tension is available consult factory.
  • Reels for fueling applications are available please consult factory.
  • Get best quote for spring rewind reels
Click the link to download a catalog.

Additional information

Reel Type

Reel Model

Reel Name

816-25-26-10.5B, 818-23-24-10.5J, 818-25-26-10.5 SD, 818-25-26-10.5B, 820-25-26-10.5A, 820-30-31-10.5A, 820-30-31-15.5A(W 3/4" OUTLET)
